Red Light Revolution Erupts as Chinese Scientists Set Jaw-Dropping Efficiency Record With Purest and Brightest LEDs Ever

The realm of optoelectronics has recently witnessed a groundbreaking advancement, thanks to the efforts of scientists from the University of Science and Technology of China (USTC). These researchers have engineered the brightest and most efficient pure-red perovskite light-emitting diodes (PeLEDs) ever created. The significance of this development is immense, as pure-red PeLEDs are pivotal for the future of vivid displays and energy-efficient lighting solutions. This achievement is particularly noteworthy because it addresses a long-standing trade-off between efficiency and brightness, which has previously hindered progress in this field. By utilizing innovative techniques and materials, USTC’s team has set a new benchmark, promising a brighter future for optoelectronic applications.

Revolutionizing PeLED Performance

The breakthrough by the USTC team is not just about minor improvements but a revolutionary leap in PeLED performance. Achieving a peak external quantum efficiency of 24.2% and a maximum brightness of 24,600 candelas per square meter, these PeLEDs are unparalleled in their category. This leap was made possible by addressing the issue of “carrier leakage,” which plagued 3D mixed-halide perovskite materials such as CsPbI_3-xBr_x. Carrier leakage resulted in electrical charges escaping before being converted into light, significantly reducing efficiency under high current conditions.

By developing and implementing a specialized tool known as electrically excited transient absorption (EETA) spectroscopy, the researchers were able to perform real-time analysis of carrier dynamics within operating devices. This diagnostic tool enabled them to precisely identify the cause of leakage, which primarily occurred due to hole leakage into the electron transport layer. This breakthrough has allowed the USTC team to engineer solutions that enhance the efficiency and brightness of PeLEDs significantly.
